Description
TECHNICAL DATA AND STANDARD ACCESSORIES
- Movable head 45° left – 90° right
- Reduction unit oil bath
- Double hinged pin with eccentric bush
- Quick locking vice complete with anti-burr device
- Membrane pump for coolant
- Coolant filter
- Jet separation system to keep the blade oiled
- Sliding countervice for longitudinal cutting
- Bar support arm
- Bar stop
- Service tools
- Instruction manual and spare parts list
- 24 V low voltage installation with hold-to-run head control knob
- Overall dimensions: 1475 mm x 1000 mm x 1200 mm.
ACCESSORIES ON REQUEST
- Pedal controlled pneumatic vice
- Three phase electric motor 20 – 40 rpm
- Steel pedestal
Download the technical sheet
