TECHNICAL DATA AND STANDARD ACCESSORIES

• Automatic CNC hydraulic shear performing cuts from 0° to 60° to the right and produced according to the current safety standards
• The equipment is supplied with 9 programs, each of them with 99 steps for a total of about 890 cutting positions with relevant piece-counter
• Operation:
  1. Material feeding
  2. Fixed vice lock
  3. Rotation of the blade and delivery of the coolant, bow down-feed untill the finishing of the cut, feeding carriage return until the fixed measure
  4. Bow return, blade revolution and coolant delivery stopping
  5. Vice opening
  6. Cycle repetition
• Step by step feeding with ball screw system
• Digital control of quality and cutting lenght
• Hydraulic jack with regolation of cutting pressure
• Blade tensioning obtained through manual rotation of the handwheel and guaranteed by electro-mechanical switch
• Blade cleaning device with brush
• Bimetal blade 3200 x 27 x 0,9
• Power jack hydraulic 0,75 kW
• Cutting thickness 1,2 mm
• Stroke feeder material 600 mm
• Electronic pump 0,09 kW
